X1 Pro MAX Motorcycle Bluetooth Headset - Product Introduction

Core Highlights: Upgraded to Bluetooth 5.4, with newly added special effect lights, network intercom and adjustable EQ. Supports dual-phone connection, AI voice control and 600m dual-person intercom, paired with IP67 waterproof rating and 23-hour long battery life, providing an enhanced riding communication and entertainment experience.

I. Product Overview

X1 Pro MAX has been fully upgraded, adding special effect lighting, network intercom and EQ adjustment functions. It supports both dual-person intercom for two-person trips and APP-enabled multi-person intercom for team rides, meeting diverse communication needs of riders. The upgraded voice prompt system, earphone cable and back clip design further optimize the user experience, making riding safer and more convenient.

II. Appearance Design

• Material: Adopting ABS+TPU composite material, which balances durability, flexibility and wearing comfort
• Overall Dimensions: 86mm × 40mm × 26mm
• Note: The product color and silk screen shall be subject to the confirmation of the sample prototype

III. Core Functions

1. Intercom & Connectivity

• Bluetooth 5.4: Upgraded Bluetooth version for more stable transmission, lower power consumption and faster connection speed
• Dual-person Intercom: Supports 600m long-distance intercom, meeting the communication needs of two-person riding
• APP Multi-person Intercom: Realizes unlimited-distance network intercom via APP, suitable for team riding scenarios
• Cross-brand Communication: Enables one-on-one intercom with headsets of other brands
• Dual-phone Connection: Can connect two Bluetooth devices simultaneously, such as Bluetooth GPS + mobile phone or two mobile phones

2. Intelligent Control & Voice Prompt

• AI Voice Control: Wakes up the voice assistant via the command "Hi, Pangu", supporting voice operations like answering calls, rejecting calls, switching songs, adjusting volume, playing/pausing music
• One-click Voice Assistant: Activates the mobile phone voice assistant with a single key press
• Upgraded Voice Prompt System: The voice prompt is more pleasant, with added key press prompts and a startup greeting of "Welcome to Qingqixun"
• Auto Answer Call: Enables/disables auto answer via key setting; when enabled, incoming calls are answered automatically after 10 seconds
• Auto Power Off: Smart power-saving function, automatically shuts down after 10 minutes of disconnection from any device

3. Entertainment & Lighting Effects

• Adjustable EQ: Customizes different sound effects via APP according to personal preferences
• Colorful Lighting: Upgraded lighting system with more dazzling RGB light effects, creating a personalized riding atmosphere
• Volume Synchronization: Supports independent adjustment of headset volume, prompt tone and mobile phone ringtone, with upgraded mobile phone volume synchronization function

4. Practical Upgrades & Waterproof Design

• IP67 Waterproof Rating: Professional dustproof and waterproof performance, adapting to various harsh riding environments
• Upgraded Earphone Cable: The cable material is upgraded to PVC, with stronger flexibility and longer service life
• Upgraded Back Clip: Adopts a new double-wing fitting design, with upgraded vertical buckles for more convenient device disassembly

IV. Detailed Parameter Configuration

V. Operation Guide

1. Button Functions (5-Key Design: Function Key1, M Key1, + Key1, - Key1, Light Key*1)

• Power On/Off: Long press the Function Key for 1.5 seconds to turn on/off
• Mode Switch: Short press the M Key to switch between Bluetooth mode and intercom mode; long press the M Key for 1.5 seconds in intercom mode to start intercom pairing; long press the M Key for 1.5 seconds to activate the mobile phone voice assistant
• Music & Call Control: Short press the Function Key to pause/play music; short press once to answer/hang up a call when there is an incoming call; short press twice to reject a call; short press twice to redial after successful Bluetooth connection
• Light Control: Short press the Light Key to switch light modes; long press to enable/disable auto answer call
• Volume & Song Adjustment: Short press the + Key to increase volume; long press to switch to the next song; short press the - Key to decrease volume; long press to switch to the previous song
• Disconnect Bluetooth: Short press + Key and - Key simultaneously to disconnect the current Bluetooth device
• Hard Reset: Long press the Function Key for 8 seconds to reset the device

2. Interface Definition

• Type-C Interface: Charging port, DC5V1A input
• Mini USB Interface: Speaker interface for audio output

3. Indicator Light Status

• Indicators: 1 Red-Blue Dual-color LED (Mode Key Light), 2 RGB LEDs (Function Key Light), 1 RGB LED (Tail Light)
• Mode Key Light: Slow blue flash during Bluetooth search; blue flash when Bluetooth is connected successfully; fast blue flash during active intercom search; slow blue flash during passive intercom search; blue flash when intercom is connected successfully
• RGB Lights (Tail Light & Function Key Light): Colorful gradient when powered on
• Charging Indicator: Red light stays on during charging; red light turns off when fully charged

VI. Packaging Accessories

Standard Accessory List (Fully Equipped, Ready to Use Out of the Box):

• Top and Bottom Cover Color Box
• 2-in-1 Headphone Microphone (Replaceable Full-face/Half-face Microphone)
• Headphone Microphone Spring *1
• Type-C Charging Cable *1
• Microphone Fixing Sheet (Velcro Design) *2
• Headphone Fixing Sheet (Velcro Design) *2
• Velcro Heightening Pad *2
• Alcohol Pad *1
• Operation Manual & Warranty Card

VII. Certification Requirements

• Battery Certification: MSDS, UN38.3
• Other Certifications: Meet customer requirements (compliant with CE, FCC certification standards)

VIII. Testing & Inspection Standards

• Aging Test: Mandatory for mass-produced finished products
• Environmental Test, ESD Test, Charge-Discharge Test and other reliability tests: Comply with Weile Electronic Product Reliability Test Standards
